Marin
Marin: Rift Zone E - 2024 SALE
Marin | Rift Zone E | Grey Blue

Marin

Marin: Rift Zone E - 2024 SALE

$4,499.00
$3,999.00
(You save $500.00 )
(No reviews yet) Write a Review
Condition:
New
Adding to cart… The item has been added

Description

Marin: Rift Zone E  - 2024 SALE



Experience the unbeatable combination of power, precision, and price with the Marin Rift Zone E.
Unleash the full potential of every ride with the Marin Rift Zone E electric bike at Bike Attack. Engineered for the thrill-seekers and trail-blazers, this electric mountain bike features cutting-edge Shimano drive unit for that extra boost and Shimano drivetrain for performance. Your adventures are now longer, faster, and more exhilarating. The Marin Rift Zone E is your ticket to maximized fun on every terrain.



MOUNTAIN BIKING WITH A BOOST



THE JACK-OF-ALL-TRADES MTB, ELECTRIFIED



MAXIMIZING FUN

One of the very best value eMTB’s around, the base model Marin Rift Zone E packs a crazy-powerful punch without busting the bank. RockShox and X-Fusion handle the suspension, Shimano Deore brings a tough, reliable 10-speed drivetrain and Shimano’s STEPS EP6 drive unit powers you up, along and down. A 504WH battery is supplied as standard, with the option to upgrade to a beefy 630WH for even more range.



SPECIFICATIONS

  • FRAME

    All New Series 4 Alloy Frame, 140mm MultiTrac Suspension, Integrated Battery/Charging Port, 148mm Rear Thru-Axle, Built-in Rear Speed Sensor

  • FORK

    RockShock 35 Silver R 29", Motion Control Damper, 140mm Travel, Maxle Stealth Axle, 42mm Offset

  • SHOCK

    X-Fusion 02 PRO R, Compression and Rebound Adjustment, Custom Tune, 210x55 25xM8 Lower Mount & Upper Mount

  • RIMS

    Marin Aluminum Double Wall, 29" Diameter, 29mm Inner Rim Width, Pinned Joint, Disc Specific, Tubeless Compatible

  • HUB REAR

    Shimano HB-TC500, 148x12mm, Centerlock, Standard Freehub Body

  • HUB FRONT

    Shimano FH-TC500, 110x15mm, Centerlock, 32H

  • SPOKES

    14g Black Stainless Steel

  • TIRES

    Vee Tire Co. Attack HPL, 29x2.5", Top 40 Tubeless Compatible, Override E-Specific Casing

  • DERAILLEUR REAR

    Shimano Deore, Direct Attachment, 10-Speed SGS

  • SHIFT LEVER

    Shimano Deore, 10-Speed, I-Spec EV

  • CRANKSET

    Shimano EM600, 160mm Length, 38t Chainring

  • MOTOR

    Shimano Steps EP6 Drive Unit, 250W, 85Nm, 20MPH Top Assisted Speed



  • CHAIN

    KMC X-10E, Silver

  • CASSETTE

    Shimano Deore 10-speed 11-46T

  • BRAKES FRONT

    TRP Slate EVO 4-Piston Hydraulic, 203mm Rotor, 2.3mm Thick

  • BRAKES REAR

    TRP Slate EVO 4-Piston Hydraulic

  • BRAKE LEVERS

    Shimano MT4100 Hydraulic, I-Spec EV Compatible

  • HANDLEBAR

    Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back

  • STEM

    Marin 3D Forged Alloy, 35mm

  • GRIPS

    Marin Grizzly Lock On

  • HEADSET

    FSA No 57E, Sealed Cartridge Bearings, 1 1/8" x 1 1/2”

  • SEATPOST

    TranzX, YSP18JL, 1x Remote, Size S 150mm Travel, All Other Sizes 170mm Travel, 30.9mm

  • SADDLE

    Marin eMTB Saddle

  • PEDALS

    Marin MTB Plastic

  • BATTERY

    Shimano BT-EN805L, Internal 504Wh

  • DISPLAY

    Shimano SC-E600



  • SWITCH

    Shimano SW-EN600L Left Hand Switch for Assist Mode Change



  • EXTRAS

    Shimano Battery Charger EC-E6002, Shimano CS-EN800 Chainguide

  • RANGE, CHARGING TIME

    15-43 miles (Based on Rider Weight, Terrain, Climate and Level of Assist Used), 4 Hours (estimated, under ideal conditions)

Specifications, pricing, and availability are subject to change without notice.



GEOMETRY

  SMLXL
STACK 606.98 614.04 625.1 634.16
REACH 445 465 485 515
HEAD TUBE ANGLE 65° 65° 65° 65°
HEAD TUBE LENGTH 100 110 120 130
SEAT TUBE ANGLE 77° 77° 77° 77°
SEAT TUBE LENGTH 390 400 425 435
TOP TUBE EFFECTIVE 585.13 607.22 629.32 661.41
BB HEIGHT 348.5 348.5 348.5 348.5
BB DROP 32 32 32 32
CHAINSTAY 440 440 440 440
WHEELBASE 1198.29 1222.52 1246.74 1280.97
STANDOVER HEIGHT 693.65 696.01 709.94 719.93
FORK OFFSET 42 42 42 42
SEATPOST DIAMETER 30.9 30.9 30.9 30.9
HANDLEBAR WIDTH 780 780 780 780
STEM LENGTH 35 35 35 35
CRANK LENGTH 160 160 160 160

All lengths in millimeters
